Specifications

• Vr – Reverse Voltage, 1000 V
• If – Forward Current, 1 A
• Type, Standard Recovery Rectifiers
• Configuration, Single
• Vf – Forward Voltage, 1 V
• Max Surge Current, 30 A
• Ir – Reverse Current, 5 uA
• Minimum Operating Temperature, – 65 C
• Maximum Operating Temperature, + 150 C
• Diffused Junction
• High Current Capability and Low Forward Voltage Drop
• Surge Overload Rating to 30A Peak
• Low Reverse Leakage Current
• Lead Free Finish, RoHS Compliant

Diode 1N4007 is used in a wide range in circuits, the most common applications:

• Used to prevent reverse polarity problem
• Used as a protection device
• Half wave and full wave rectifiers
• Current flow regulators
• Power management
• Signal processing

Equivalent replacement

The equivalents for diode 1N4007 are 1N4148, 1N4733A, 1N5408, 1N5822.
